The Last Signal. Post #4: animations

This post is about including animations in our game. This topic is too difficult to go into much detail. I will therefore only briefly go through the main points of how I (almost) solved this complex area in the game. I may return to it later when I have the time for a more thorough discussion.

I used the existing SFML Animation and AnimatedSprite classes, which are not included in the standard distribution but can be downlaoded separately. The AnimatedSprite class expands the original Sprite class allowing animations to be attached sprites and played or stopped whereas the Animation class allows to create those animations.

There was not much to do here other than go through a tutorial, copy the files and implement the same algorithm that was used by the author of these classes. The algorithm looks as follows:

    sf::Texture texture;
	if (!texture.loadFromFile("player.png"))

	// set up the animations for all four directions (set spritesheet and push frames)
	Animation Down;
    Down.setSpriteSheet(texture);
	Down.addFrame(sf::IntRect(65, 97, 64, 96));
	Down.addFrame(sf::IntRect(130, 97, 64, 96));
	Down.addFrame(sf::IntRect(195, 0, 64, 96));

	Animation Left;
    //...and so on, for every required animation

    Animation* currentAnimation = &walkingAnimationDown;

	// set up AnimatedSprite
	AnimatedSprite animatedSprite(sf::seconds(0.05), true, false);

	sf::Clock frameClock;

    while (window.isOpen())
  	{
		//... other code, e.g. event handling

		sf::Time frameTime = frameClock.restart();

		// code sets current animation to correct animation, depending on, e.g. user input
		currentAnimation = &Up;

        animatedSprite.play(*currentAnimation);

		// update AnimatedSprite
		animatedSprite.update(frameTime);

		// draw
		window.clear();
		window.draw(animatedSprite);
		window.display();

        //...

So basically, the code does the following:

1. you create an sf::texture by loading a raster image from an external file (usually called a spritesheet). An artist from our group produced this spritesheet for astronaut animations:

Spritesheets contain all the different frames, sequences of which make up the different animations. You obtain each individual frame by telling your development tool (e.g., Visual Studio) to clip a rectangular area from a spritesheet. This is seen in lines below line 5. In line 5, we declare a new animation, Down in this case, and then add frames to it via SFML’s .addFrame method. In this way you define your animations.

Then you create a version of the familiar Sprite object, an AnimatedSprite. You will tell it to use one selected animation and to update it when necessary (keep showing the different frames in the animation). Animation will need to be changed as the gameplay progresses, so you create a variable called currentAnimation which is taken in as a parameter by the .play() method. And the currentAnimation is set to different animations depending on what happens in the game.

The .update() method is what brings the actual animation alive. It tracks the in-game time and switches current frame to the next one when enough time has passed. How does it know when enough time to show the next frame has passed? This is where the deltatime variable comes into play. The deltatime is maintained elsewhere in the game architecture, usually in the Engine part and is re-calculated every “tick”, or “game frame”, i.e. every iteration of the game loop. Using it allows the said .update() method track the time and change frames when the timing is right.

Finally, the animated sprite is drawn using the usual .draw() method, because as already mentioned, it inherits from drawable and transformable classes.
